Available Options

  • HP 60, 80, 120, 180
  • Stamper
  • Fluffer


Feed Opening 94” x 41”
Bale Chamber 43” x 43” x 114”
Bale Size expandable (Adjustable) 43” x 43” x 59”
Bale Weight Up to 2,800 lbs.
Tension Cylinder 10″ Diameter, 10″ Stroke
Ram Rollers 12
Machine Weight 52,900 lbs
Main Baler Body Frame SS41
Cutting Knife Replaceable Tool Steel Scatter Cutter
Auto Tier Hydraulic Actuated Inserter
Number of Ties 5
Wire Arrangement 50, 100 spools or 1,000 stand
Ram Face Pressure 140 PSI
Tension Force 470 Tons
Tension Type 4-Way Free Floating Clamber
Cycle Time (No Load) 12 Sec.
Cycles Per Minute 5
Tie Cycle 24-30 Sec
Production (O.C.C) Up to 30 TPH
Hydraulic System Regenerative
Oil Reservoir 1000 Gallons 4600 Liters
Hydraulic Cooling Air Cooling
Hydraulic filtration Suction Filter
Hydraulic Pump Brand DENISON
Valve Brand VICKERS
PLC Mitsubishi
Operator Interface Human Machine Interface
Main Motor Control STAR/DELTA
Controller Brand Siemens
UL Standard
  • One year warranty under normal use and maintenance, except for consumables.
  • 2 and 3 year service contracts available.
  • Nationwide Service
